Cross Transfer Station with Pusher (Twin)

Transfer of product rows from the main conveyor of the packaging system to the individual feeding sections of the different packaging machines.
  • To transfer the product rows via an oscillating nose conveyor to a cross transfer conveyor respectively to the next transfer station in direction of the flow
  • Transfer of products from the oscillating nose conveyor to a transfer conveyor
  • The pusher supports the transfer of the products to the cross transfer conveyor
  • Three-phase motor driven conveyor, frequency controller integrated within the switch cabinet
  • Tilting function and product transfer conveyor driven by two separate servo motors
  • Pneumatic web tracking control
  • Easy access for cleaning through removable conveyor support plates
  • Quick tensioning devices for the conveyor belts for easy maintenance and service
  • All product transfers and scrapers with underneath sliding waste trays
  • Return shafts with diameter 10 mm for smooth product transfer
  • Optional: Additional reversible conveyor stage to allow feeding from process and/or downstream storage system
  • Optional: Simultaneous pick up of two product rows to increase capacity or for two-lane feeding of the wrapping machine
