Turning and Aligning Conveyor

System to turn and align bar and tablet shaped products (turning from long edge leading to small edge leading)
  • Reject of non properly aligned products via a reject rim
  • In two- or three-stage execution or with dual conveyor stage (two parallel conveyors with different speed)
  • Three-phase motor driven conveyor, frequency controller integrated within the switch cabinet
  • Easy access for cleaning through removable conveyor support plates
  • Quick tensioning devices for the conveyor belts for easy maintenance and service
  • All product transfers and scrapers with underneath sliding waste trays
  • Return shafts with diameter 10 mm for smooth product transfer
  • One driven product guide attached to a swivelling overhead frame for easy cleaning and maintenance access
  • Sensors to scan non – properly aligned products and to reject them via a mechanical reject rim (activating of an air blast for reject)
  • Optional: Cooling of the conveyors
